Specification:

❁ Maximum Working Pressure : 15,000 psi / 1,000 bar  (Options of 20,000 psi & 40,000 psi available)

❁ Maximum Flow Rate : 110 l/min

❁ Connection In : 1-1/2” Female NPT

❁ Connection Out : 1/2" Female NPT

❁ Water Tank Volume : 378 litres

❁ Fuel Capacity : 257 litres

Equipment Specifications:

❖ Pump : NLB Series 225 with 1-1/8” diameter plungers

❖ NLB Corp Equipment No. : NLB15305FDB

❖ Engine : Cummins QSC-505/8.3              Max 2200 Rpm, Nominal 1800 Rpm

❖ Clutch Assembly : Twin Disc, Mode SP314 Series

❖ Starter : Battery 2 x 12V

❖ Feed Water Filter : Stainless steel 25 micron filter assembly

❖ Diesel supply shutdown if;-

❁ High temperature on cooling water

❁ Low engine oil pressure

❁ Emergency shutdown

❁ Low water inlet suction pressure

Standard Features:

❖ Pump is coupled via V-Belt system through a manual clutch housing.

❖ Water pressure actuator automatically returns engine to idle if operator disengages cleaning tool.

❖ Emergency stop switch for operator
